Description
Features
- 590nm Amber (turtle & wildlife friendly)
- 2,607 Lumens
- 21 LPW
- BUG rating: 1, 2, 0
- Choice of Finish: Bronze or custom RAL colors available upon request
- IES Type V distribution
- Die-cast aluminum housing and front frame
- Nickel-plated stainless steel hardware
- Integral heat sinking and driver compartment
- Photocell Adaptable
- L70 @ 429,000 hours (EXTREME-LIFE)
- CSA listed for wet locations
- IP66 sealed LED compartment
- Textured architectural bronze powdercoat finish over a chromate conversion coating
- Tempered clear flat glass lens
- Mounted with arm, adjustable slip fitter, 2⅜˝ Diameter Mounting Arm Adapter, yoke, two-piece bracket, or Easy Hang Wall Bracket (factory Installed)
- Electronic driver
- 120-277v, or 347-480v
- 120-277VAC 10KA Surge Suppressor
- 347-480VAC 10KA Surge Suppressor
- 0-10V Dimming Standard for a Dimming Range of 100% to 10%; Dimming Source Current is 150 Microamps
- Operating temperature: -40°C~+50°C environment
Options
- Choice of Finish: Bronze or custom RAL colors available upon request
- Motion sensors available for heights of 20′ – 35′ or 18′ or less
- Pencil photocell 120-277VAC
- Die-cast adaptor for 3″ to 4″ poles for use with CARA mounting arm only
- Die-cast wall mount adaptor for use with CARA mounting arm only
- All brackets include hardware
- Narrow beam (30°)
- Motion Sensor IR with Lens, 120-277V Only, for heights up to 40′
- Motion Sensor IR with Lens, 120-277V Only, for heights up to 20′
- 3-Pin Twist Lock Photocell Receptacle
- 5-Pin Twist Lock Photocell Receptacle
- 7-Pin ANSI C136.41—2013 Twist Lock Photocell Receptacle
- Microwave Sensor with Dimming, 120-277V only
- Microwave On/Off Motion Sensor – NO Dimming, 120-277V Only
- 120-277VAC Universal Twist Lock Photocell
